| Thinking about adding Braille signage? Did you know that only 6% of the population of people who are legally blind can read Braille? |
| Recently a new community centre opened with typical fanfare and support from the surrounding neighbors. That is, from everyone but those among the disability community. Here are a few examples of what we found when we audited the facility. The building was constructed with a curb located along the front entrance with no curb-cut or ramp to allow a person with a disability to easily access the front door from the parking lot.** The toilets in the accessible stalls were too high and uncomfortable for people to use. The toilet paper dispensers were mounted too close to the grab bars; making it difficult to reach and hold onto the grab bars when transferring on and off the toilet. Elevators were installed to allow wheelchair access to the upper floors, but to preserve floor space in the building the elevators were so small that a person using a wheelchair could not turn to face the control panel to select the floor once they were inside the elevator car. When asked how so many things could be wrong with a new building that was intended to be accessible, the architect replied, "The client didn't specify what they meant by being accessible." |
| Don't make the same mistake. Ensure that your facility is meeting approved guidelines. Don't assume the Building Code provides the answers to accessibility. It doesn't. In fact, the simple selection and mounting of a grab bar in the accessible toilet stall is case in point. According the Ontario Building Code,a grab bar should be a straight bar mounted on an angle on the wall beside the toilet. Most public washrooms have complied. The problem is, an angled grab bar does not provide a stable surface for the person to safely hold while transferring on or off the toilet -- its on an angle. What is needed is a "L" shaped grab bar -- one that provides a flat surface to place your body weight and the straight upward section of the bar gives leverage to pull oneself up to a standing position when getting off the toilet. Many municipalities in Canada have accepted the Facility Accessibility Design Standards, or the Canadian Standards Association for the Built Environment. Either of these will provide far more useful information than the Building Code when it comes to the needs of people with disabilities. Sterling Frazer Associates are not recommending that you ignore the Building Code as it does provide important safety information for the construction of your facility. We are simply pointing out that in a document that is a couple inches thick, only 8 pages are dedicated to accessibility. After all, its your building, your customers will judge you not the architect or building inspector when they can not access your services. |
| A Case Study in Accessibility |
